There are currently 41 modern double hull tanker under the technical management of LSC, with plans to expand
Ugale
Class
Det Norske Veritas 1A1 Tanker for Oil and Chemicals, ESP, EO, SPM, ICE 1B, DAT (-20 OC), TMON NAUTICUS (New building) IMO Ship type 3.
Built by
3. Maj ShipYard, Rijeka, Croatia
Built in
2007
Flag
the Marshall Islands
Call sign
V7LO3
IMO NO.
9323352
Loading capacity (t)
52600

Technical specifications



MAIN DIMENSIONS  MACHINERY CARGO HANDLING
Length over all:                  195.165 m.                Main engine:            WARTSILA 7 RTA 48T-B                    Cargo pumps: 14 hydraulic deepwell pumps, 12 centrifugal pumps capacity 550 m³/h each, 2 cetrifugal pumps capacity 300 m³/h each

Breadth moulded:

32.20 m.

Nominal output:

9650 kW Heating: Deck heaters
Depth moulded: 17.80 m. Fuel: FO 380 CST Tank cleaning system:  Fixed tank cleaning machines
Draught maximum: 12.50 m. Bow thruster: No IGS: Yes - I. G. generator
Tons per cm of draught: 56,81 t. Service speed: 14.0 knots


CAPACITIES TONNAGE (t) MANIFOLD DERRICKS/CRANE CARGO TANK COATING
(98% volume) m3   INTERNATIONAL 1 crane 10.0 mt capacity          Phenolic Epoxy
Total cargo tank: 56150.7 GRT NRT
Slop tanks: 1348.3 30641 15308
Total capacity: 57728.8
Grades of cargo: 4
SBT: Wing tanks Nos 1 – 6, forepeak, afterpeak
SBT capacity: 24058.4
Bunker capacity: FO 1559.3
DO 183.6
